- 매우 높은 정확도와 반복성을 달성합니다.
- 적절한 응용 프로그램에 맞게 기기를 최적으로 매치합니다.
- 키를 사용하거나 푸시 버튼을 사용하여 직접 매개변수를 선택하세요
- 투과 렌즈 뷰파인더 또는 레이저 타겟팅 라이트를 사용하여 고온계의 정확한 정렬을 달성합니다.
- 디지털 방식으로 빠르게 신호를 처리합니다
사양
| 작동 온도 범위(°C): | 250~3500°C(17개 범위) |
|---|---|
| 스펙트럼 범위(µm): | 0.7과 1.8(그 사이의 2개 범위) |
| 측정 불확도(°C): | 0.3% 또는 + 1 °C부터 |
| 광학(mm): | 고정 광학 장치, 초점 조절 광학 장치 |
| FOV(최소 스팟 크기)(mm): | 최소 900:1 (0.1) |
| 정렬 / 조준: | 레이저 타겟팅 또는 렌즈 조준 |
| 인터페이스/출력(mA): | 0/4 ~ 20mA |
| 노출 시간 t90(ms): | 1밀리초 |
| 주변 온도(°C): | 0~70 |
| 해상도(°C): | 0.1 |
| 디스플레이: | 내장 5자리 LED 디스플레이, 추가 기능 LED |
| 보호 등급: | IP65(DIN 40 050에 따름) |
| 방사율: | 0.1% 단위로 0.100~1.000 |
| 무게(kg): | 2.2 |
| 주택: | 알루미늄 다이캐스팅 |
| 연결: | 12핀 커넥터 |
| 작동 위치: | 어느 |
| CE 라벨: | 전자파 면역에 관한 EU 지침에 따르면 |
| 격리: | 전원 공급 장치, 아날로그 출력 및 디지털 인터페이스는 서로 전기적으로 절연되어 있습니다. |
| 파장 반복성(pm): | 0.1% 또는 + 1 °C |
부품번호
| Part Number | 출력 유형 | 광학 | 정렬 | 응답 시간 | 최소. 온도(°C) | 최대. 온도(°C) | 애플리케이션 |
| 3 839 100 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 550 | 1400 | Metal / Ceramics / Graphite |
| 3 839 110 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 550 | 1400 | Metal / Ceramics / Graphite |
| 3 839 120 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 550 | 1400 | Metal / Ceramics / Graphite |
| 3 839 130 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 550 | 1400 | Metal / Ceramics / Graphite |
| 3 839 150 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 600 | 1600 | Metal / Ceramics / Graphite |
| 3 839 160 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 600 | 1600 | Metal / Ceramics / Graphite |
| 3 839 170 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 600 | 1600 | Metal / Ceramics / Graphite |
| 3 839 180 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 600 | 1600 | Metal / Ceramics / Graphite |
| 3 839 200 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 650 | 1800 | Metal / Ceramics / Graphite |
| 3 839 210 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 650 | 1800 | Metal / Ceramics / Graphite |
| 3 839 220 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 650 | 1800 | Metal / Ceramics / Graphite |
| 3 839 230 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 650 | 1800 | Metal / Ceramics / Graphite |
| 3 839 250 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 750 | 2500 | Metal / Ceramics / Graphite |
| 3 839 260 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 750 | 2500 | Metal / Ceramics / Graphite |
| 3 839 270 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 750 | 2500 | Metal / Ceramics / Graphite |
| 3 839 280 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 750 | 2500 | Metal / Ceramics / Graphite |
| 3 839 300 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 550 | 2000 | Metal / Ceramics / Graphite |
| 3 839 310 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 550 | 2000 | Metal / Ceramics / Graphite |
| 3 839 320 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 550 | 2000 | Metal / Ceramics / Graphite |
| 3 839 330 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 550 | 2000 | Metal / Ceramics / Graphite |
| 3 839 350 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 700 | 3500 | Metal / Ceramics / Graphite |
| 3 839 360 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 700 | 3500 | Metal / Ceramics / Graphite |
| 3 839 370 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 700 | 3500 | Metal / Ceramics / Graphite |
| 3 839 380 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 700 | 3500 | Metal / Ceramics / Graphite |
| 3 839 600 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 250 | 1000 | Metal / Ceramics / Graphite |
| 3 839 610 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 250 | 1000 | Metal / Ceramics / Graphite |
| 3 839 620 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 250 | 1000 | Metal / Ceramics / Graphite |
| 3 839 630 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 250 | 1000 | Metal / Ceramics / Graphite |
| 3 839 650 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 300 | 1300 | Metal / Ceramics / Graphite |
| 3 839 660 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 300 | 1300 | Metal / Ceramics / Graphite |
| 3 839 670 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 300 | 1300 | Metal / Ceramics / Graphite |
| 3 839 680 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 300 | 1300 | Metal / Ceramics / Graphite |
| 3 839 700 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 350 | 1800 | Metal / Ceramics / Graphite |
| 3 839 710 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 350 | 1800 | Metal / Ceramics / Graphite |
| 3 839 720 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 350 | 1800 | Metal / Ceramics / Graphite |
| 3 839 730 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 350 | 1800 | Metal / Ceramics / Graphite |
| 3 839 750 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 400 | 2300 | Metal / Ceramics / Graphite |
| 3 839 760 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 400 | 2300 | Metal / Ceramics / Graphite |
| 3 839 770 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 400 | 2300 | Metal / Ceramics / Graphite |
| 3 839 780 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 400 | 2300 | Metal / Ceramics / Graphite |
| 3 839 800 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Viewfinder | 1 | 250 | 1400 | Metal / Ceramics / Graphite |
| 3 839 810 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1 | 250 | 1400 | Metal / Ceramics / Graphite |
| 3 839 820 | 0/4 to 20 mA / RS232 / RS485 | Focusable | Laser Target / Viewfinder | 1 | 250 | 1400 | Metal / Ceramics / Graphite |
| 3 839 830 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1 | 250 | 1400 | Metal / Ceramics / Graphite |
| 3 840 200 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1.5 | 350 | 900 | Aluminum |
| 3 840 210 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1.5 | 350 | 900 | Aluminum |
| 3 840 220 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 1.5 | 400 | 1050 | Aluminum |
| 3 840 230 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder / Scanner | 1.5 | 400 | 1050 | Aluminum |
| 3 840 300 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 10 | 400 | 900 | Silicon Wafer |
| 3 840 310 | 0/4 to 20 mA / RS232 / RS485 | Fixed | Laser Target / Viewfinder | 10 | 350 | 1000 | Silicon Wafer |
